Advanced Temperature Control PID Controller

This board is an option to the board since it uses its oven, the heating element and the temperature transducers. This board includes two reference signal generators, a comparison node and the three terms network (proportional, integral and derivative). The board is supplied complete with a set of stackable, plug-in cables of suitable lengths and colours and with a training manual. Complete with digital temperature indicator 100mV/°C.
Power supply: ± 15Vdc, 100mA and +5Vdc, 150mA

Experiments:
PID controllers calibration
PID control circuits.
Analysis of the operation of a proportional, proportional-derivative and proportional integral control.
