Air Conditioning System Trainer H Block

The trainer uses the H-Block TXV design of refrigerant flow control. The trainer uses common automotive components and can be used in both classroom and shop environments. The Air Conditioning System Trainer H Block  is a complete A/C system with unique features designed to enhance the instruction of air conditioning physics. The trainer utilizes a hermetically sealed and internally protected compressor. Operates on 120V 15A 60Hz circuit.

Advantages:
Fully operational with typical component layout and organization.
Clear sight glasses provide clear understanding of the H-Block (TXV) air conditioning refrigeration cycle.
Trainer has all major components required for an automotive air conditioning system using the H-Block TXV system.
Trainer can be connected to any A/C Recycling/Recovery equipment using R134a service ports.
Allows student observation of refrigerant changes of state (liquid/vapor) at the receiver/drier, evaporator and condenser.

Features:
High pressure (300psi) safety switch shuts off compressor.
Cycling switch bypass toggle switch.
Internally protected hermetically sealed A/C compressor.
A/C compressor has manual starter with internal thermal protection.
Stainless steel condensate drip pan with drain.
Adjustable 3-speed evaporator (1) and condenser (2) fans.
