Continuous Beam

Continuous Beam

Product Code: LBNY-0005-13900016

Categories: Civil Lab Structures Equipment

Tags: Continuous Beam

3599

Download PDF Enquire Now
  • Description

Continuous Beam is to be used with Universal Structural Frame. The settlement of each load measuring support is measured by a dial gauge and can be simulated by height compensation mechanism. The Continuous Beam equipment consists of a two span continuous beam supported by two vertical force supports and a built-in/knife edge support. The Continuous Beam equipment is used for measurement of the reactions of a two span continuous beam with and without settlement of a support. Each beam deflection is measured by a dial indicator. Three movable load hangers with a set of weights for downward as well as upward loading are provided.



Specification

Test beam
Aluminum : 1 ea.
Steel : 2 ea.
Brass : 1 ea.
Vertical Force Supports : 2 ea.
Pulley assembly for upward loading : 1 ea.
Built-in/Knife Edge Support : 1 ea.
Dial Indicators : 2 ea.
Weights : 1 lot.
Load hangers : 3 ea.
