Cutaway Over Center Variable Displacement Pump

Cutaway Over Center Variable Displacement Pump

Product Code: LBNY-0005-121000143

Categories: Automobile Cutways and Models Lab

Tags: Cutaway Over Center Variable Displacement Pump

2352

Download PDF Enquire Now
  • Description

The Cutaway Over Center Variable Displacement Pump trainer is an application that can be chosen to demonstrate the operation of a hydraulic over-center pump.

Educational Advantages:
The pump housing is cutaway to expose the internal components
The barrel is cutaway to expose the pistons
The rear cover is cutaway to expose the pressure relief valve
The pump is lightweight and easy to handle
The swash plate moves
Large knob on output shaft makes it easy to rotate
The charge pump housing is cutaway to expose the charge pump and the charge pressure relief valve
Includes stand.



Specification

Cutaway Over Center Variable Displacement Pump
