HGV Rear Axle With Locking Differential Cutaway

HGV Rear Axle With Locking Differential Cutaway

Product Code: LBNY-0005-121000328

Categories: Automobile Cutways and Models Lab

Tags: HGV Rear Axle With Locking Differential Cutaway

2538

Download PDF Enquire Now
  • Description

Main components:
Axle shafts
Brakes with jaws/drum
Bevel gear (pinion crown)
Differential (satellite and planetary) with locking differential
Double air brake element
Reducer and planetary on the hub.



Specification

Equipment Layout: On Stand with Wheels
Operated: Manually (Through a Crank Handle)
Dimensions: 235 x 95 x 105(h) cm
Net Weight: 590 kg
Gross Weight: 700 kg.
