Power Electronics Board

The Power Electronics Board allows the study of several power electronics circuits, as detailed here under.

Technical Features:
The following components are available of Power Electronics Board:
Pulse generator for SCR control
Generator for H Bridge control
Diodes for circuit
Three-phase generator
Single-phase source Built-in power supply
SCR for circuit
H bridge with MOSFET
Function Generator.

Experiments:
Single-phase controlled rectifier
Single-phase uncontrolled rectifier
Three-phase, full wave, uncontrolled rectifier
Three-phase, full wave, controlled rectifier
Pulse Width Modulation circuit to control direct current
Three-phase, single wave, uncontrolled rectifier
Three-phase, single wave, controlled rectifier.
