Temperature Basic Control

Product Code: LBNY-0005-12400084

Categories: Electronics Equipment

Tags: Temperature Basic Control

3020

Download PDF Enquire Now
  • Description

The board is supplied complete with a set of stackable, plug-in cables of suitable lengths and colours and with a training manual. This board includes a small oven with a heating element and three temperature sensors (thermocouple, thermistor, and thermo-resistance) with relevant interface circuits. Complete with error amplifier that can be configured for on-off or proportional control, and with a piloting circuit of the power stage with triac.
Power supply: 24Vac, 1A, 50/60Hz and 15Vdc, 100mA

Experiments:
Analysis of the operation of a proportional control
Analysis of the operation of an on-off control
V = f (t°) characteristics of a thermocouple, with relevant linearization, of the thermistor and of the thermo - resistance.
